100mm Butterfly Motorized Valves

loading

-Electric actuator, automatic control;
-Wafer connection butterfly valve;
-EPDM seat, cast iron body with epoxy painting
Availability:
  • FP1003

  • Flowx

  • 8481202000


We offer a complete range of FLOWX Butterfly Valves from general purpose to heavy duty and high performance models. These economical butterfly valves are known for their reliability, long service life, and reduced operating costs.


FLOWX  Butterfly Valves can be ordered with or without Pneumatic Actuators or Electric Actuators assembly. If requested, a valve expert will work with you to determine the best assembly for your application.


Not what you're looking for? Return to Valves or Contact our experts.



  Feature


  • Bubble-tight shut off at full pressure rating

  • Seat and disc are the only two valve parts in contact with the medium

  • Superior design for abrasive and erosive media

  • Very low pressure drop

  • Top bushing absorbs side thrust loads

  • Hub seal provided by preloaded contact between flatted seat surface and disc hub area for positive sealing at all disc positions

  • One-piece wafer thin disc stem gives the very minimum to obstruction to flow

  • Field replaceable seat isolates the body and stem from the flow

  • Molded-in O-rings provide flange sealing and eliminate need for gaskets


  Resources


Butterfly Valve Catalogs  Download



Size Range2" - 20" (50mm - 500mm)
Body StyleWafer, Lug
Temperature Range-20℃~155℃
Pressure RatingsBidirectional Bubble-tight Shutoff: to 175 psi (12 Bar)

Body (CWP): 250 psi (17.2 Bar)
Body MaterialsCast Iron, Ductile Iron, Carbon Steel, Aluminum
Disc MaterialsNylon 11 Coated Ductile Iron, Aluminum Bronze, Stainless Steel, Hastelloy?*, Halar?* Coated Ductile Iron
Stem MaterialsStainless Steel, Monel K500
Seat MaterialsBUNA-N, EPDM, FKM*, Polyurethane
ApplicationsPotable Water, Wastewater, Seawater, HVAC


Pneumatic “DA” and “SR” Series

TypeDA series is double acting and SR series is spring return (rack and pinion)
Normal Supply PressureDA: 40 to 115 psi (2.7 to 7.9 bar); SR: 80 psi (5.5 bar)
Maximum Supply Pressure120 psi (8.6 bar)
Air Connections:DA01DA01: 1/8" female NPT; DA02 to DA05: 1/4" female NPT; SR02 to SR07: 1/4" female NPT
Housing MaterialAnodized aluminum body and epoxy coated aluminum end caps
Temperature Limits-40 to 176°F (-40 to 80°C)
Accessory MountingNAMUR standard


Electric “FLX” and “FLX-E” Series

Power Requirements110 VAC, 220 VAC, 24 VAC or 24 VDC (MD models not available in 24 VDC)
Power ConsumptionSee instruction manual
Cycle Time (per 90°)FLX-01: 4 s; 01: 10 s; FLX-02 and FLX-E 02: 20 s; FLX-03 and FLX-E03: 30 s
Duty Rating85%
Enclosure RatingNEMA 4X (IP67)
Housing MaterialPowder coated aluminum
Temperature Limits-22 to 140°F (-30 to 60°C)
Electrical Connection1/2" female NPT
Modulating Input4 to 20 mA
Standard FeaturesManual override, position indicator, and TD models come with two limit switches



FLOWX is a leading industrial valve supplier manufacturer, providing flow control and automation solutions for 30+ industries.


Solution coverage: Marine & Shipbuilding, Water Treatment Industry, Filling Industry, Plastic Industry (Pneumatic Conveying), Metallurgical Industry, Chemical industry, New Energy, Electronic Industry, Break Away Denitrification Industry, Petroleum Industry, Food, Powder Industry, Power Plant Industry, etc.
