PRODUCT DETAIL

Double Offset Butterfly Valve Manufacturers in Europe

Double offset butterfly valve also called as the high performance butterfly valve, design features: epoxy coating, double offset design, one-way medium flow direction of explosion-proof rod (indicated by arrow of valve body). Metal seal can be applied to medium with slight particles and slurry, which has almost no friction and ensures less torque and better sealing

  • FP100
  • Flowx
  • 8481202000

Double Offset Butterfly Valve Manufacturers in Europe


Feature

Size Range 2" - 48" (50mm - 1200mm)
Connection Wafer, flange
Temperature Range -40℃~400℃
Pressure Ratings PN10~40
Body Materials Cast Iron, WCB, Ductile Iron, SS304, SS316, 2205, 2207
Disc Materials SS304/SS316/2205/2207
Stem Materials SS410, Monel K500
Seat Materials RPTFE
Medium Potable Water, Steam, Oil, Corrisive Medium
Actuator Feature


Pneumatic “DA” and “SR” Series

Type DA series is double acting and SR series is spring return (rack and pinion)
Normal Supply Pressure DA: 40 to 115 psi (2.7 to 7.9 bar); SR: 80 psi (5.5 bar)
Maximum Supply Pressure 120 psi (8.6 bar)
Air Connections:DA01 DA01: 1/8" female NPT; DA02 to DA05: 1/4" female NPT; SR02 to SR07: 1/4" female NPT
Housing Material Anodized aluminum body and epoxy coated aluminum end caps
Temperature Limits -40 to 176°F (-40 to 80°C)
Accessory Mounting NAMUR standard

Electric “FLX” and “FLX-E” Series



Power Requirements 110 VAC, 220 VAC, 24 VAC or 24 VDC (MD models not available in 24 VDC)
Power Consumption See instruction manual
Cycle Time (per 90°) FLX-01: 4 s; 01: 10 s; FLX-02 and FLX-E 02: 20 s; FLX-03 and FLX-E03: 30 s
Duty Rating 85%
Enclosure Rating NEMA 4X (IP67)
Housing Material Powder coated aluminum
Temperature Limits -22 to 140°F (-30 to 60°C)
Electrical Connection 1/2" female NPT
Modulating Input 4 to 20 mA
Standard Features Manual override, position indicator, and TD models come with two limit switches




Detail

details

Accessories


                    Photo       Model Code                               Description
General-Electric-Actuator-400-400





             FLX


1.The Series is a low profile,compact, powerful actuator with customer-friendly features.

2.Manual declutchable handle lever.

3.Local high visibility dome postion indicator.

4.Digital interface available.

5.Optional microprocessor based moudulating control.

 Pneumatic-Actuator4







          FLXDA/SR

Quarter Turn Double Acting Pneumatic Actuator have this feature.
1.Rack and pinion actuator available in doubule acting spring returnicals.
2.Standard units have anodized aluminum bodies with polyster coated end caps.
3.Internal bidirectional travel stops.
4.Seacorr coating for harsh enviroments.
5.SIL3 capable.
6.Inregral porting.
7.NAMUR accessory compatible.

   2-5 Way,2-3 Way Solenoid Valves




        FLXC/JZ


1.Weatherproof NEMA4,4X and explosion proof housings available

2.Flying leads to DIN Connectors

3.Single or dual Coil

4.2/5 or 2/3 Operation

5.NAMUR mounted

6.High flow up to 1.4Cv

7.Intrinsically safe versions available

Limit Swtich





        FP04ZC


1.Discrete staus monitor for quarter turn rotary actuators

2.NEMA4.4X and IP66,IP67 ingress protection

3.High visibility done position indicator

4.Up to 6SPDT switches or non-contacting proximity switches

5.Switch pre-wired to internal teminal block

Application


应用行业 拷贝


Company


工厂750

Flowx was established in 2006, we have been focusing on the development, production, sales and service of self-controlled valves for many years. Our products mainly include butterfly valves, ball valves, regulating valves, general valves, actuators and accessories.

Through more than ten years of on-site application and inspection, our products have been able to meet the stringent requirements of today's fluid handling industry, and the variety of products has increased year by year, involving a wider range of industries.

In 2018, we established a valve production base in Jinshan District, Shanghai, covering an area of 25,000 square meters. We have introduced more advanced production equipment and expanded a number of production lines, which will provide more and more for the whole country and the world in the future. Good quality self-control valves and accessories.
