Ship exhaust gas treatment system

Ship exhaust gas treatment system:

Industrial background:
Ship exhaust gas treatment system is the international maritime organization (IMO) MARPOL convention mandatory installation of key environmental protection equipment for ship diesel engine exhaust gas desulphurization and denitration harmless treatment, to prevent the air pollution caused by ship exhaust gas uncontrolled, emissions
Technical route:
The ship exhaust gas treatment system mainly includes two sub-systems of out-of-stock and desulfurization. It uses a variety of sensors (pressure, temperature, flow, No, etc.) to collect important parameters in the operation process, and realizes the intelligent control of the entire system through man-machine interactive control
Project
Products
Electric actuator specifcation: ON-OFF TYPE, 4- 20MA regulator type function Explosive-proof or non explosive proof.
Voltage  available: DC12,DC24V,AC110V,AC220V,AC240,AC380V
Running times: 10S, 30S, 60S

Pneumatic actuator specification: Double acting/single acting Pneumatic actuator, NAMUR mount Airline. Anodized aluminum actuator, working air pressure: 6-7Bars, rack & pinion type.

Valve structure: Threaded(two pieces,three pieces)
Valve size: DN10~DN100
Valve Body: WCB, SS304, SS316, SS316L
Valve Ball: SS304, SS316, SS316L
Valve Pressure: PN10,PN16, ANSICL150/CL300/CL600, JIS10K/20K
Working Temperature: -15~150℃
Working media: Seawater, Cooling water, Wastewater, pure water

Electric actuator specifcation: ON-OFF TYPE, 4- 20MA regulator type function Explosive-proof or non explosive proof.
Voltage  available: DC12, DC24V, AC110V, AC220V, AC240, AC380V
Running times: 10S, 30S, 60S

 Pneumatic actuator specification: Double acting /single acting Pneumatic actuator, NAMUR mount Airline. Anodized aluminum actuator, working air pressure: 5-7Bars, rack & pinion type.

Valve structure: wafer type
Valve size: DN40~DN1200
Valve Body: WCB, Ductile iron, SS304, SS316,
Valve Disc: Aluminum bronze C954, SS304, SS316
Valve Seat: EPDM,NBR
Valve Pressure: PN10, PN16, ANSICL150/CL300/CL600, JIS10K/20K
Working Temperature: -15~85℃
Working media: Seawater, Cooling water, Wastewater, pure water

Non return Check Valve
Non return Check Valve
Body: Ductile Iron, WCB or SS304, SS316
Disc: Aluminum bronze C954, SS304,SS316
Seat: NBR, Metal hard
Presure: ANSICL150,PN10  PN16,JIS10K 20K
End connection: Wafer
Working Temperature: -15~120℃
Working media: Seawater, Cooling water, Wastewater, pure water

Globe Valve
Material: WCB, SS304, SS316
Seat: Metal hard
Pressure: PN10, PN16, ANSICL150, ANSICL300, JIS10K
End connection: Flange, Thread.
Working Temperature: -15~120℃
Working media: Seawater, Cooling water, Wastewater, pure water

Electric actuator specifcation: ON-OFF TYPE, 4- 20MA regulator type function Explosive-proof or non explosive proof.
Voltage  available: DC12,DC24V,AC110V,AC220V,AC240,AC380V
Running times: 10S, 30S, 60S

Pneumatic actuator specification: Double acting /single acting Pneumatic actuator, NAMUR mount Airline. Anodized aluminum actuator, working air pressure: 6-7Bars, rack & pinion type.

Valve structure: RF /FM Flanges
Valve size: DN15~DN200
Valve Body: WCB,SS304,SS316,SS316L
Valve Ball: SS304, SS316, SS316L
Valve Pressure: PN10, PN16, ANSICL150/CL300/CL600, JIS10K/20K
Working Temperature: -15~150℃
Working media: Seawater, Cooling water, Wastewater, pure water

Electric actuator specifcation: ON-OFF TYPE, 4- 20MA regulator type function Explosive-proof or non explosive proof.
Voltage  available: DC12, DC24V, AC110V, AC220V, AC240, AC380V
Running times: 10S, 30S, 60S

 Pneumatic actuator specification: Double acting /single acting Pneumatic actuator, NAMUR mount Airline. Anodized aluminum actuator, working air pressure: 5-7Bars, rack & pinion type.

Valve structure: Flange type
Valve size: DN50~DN1000
Valve Body: WCB,Ductile iron,SS304,SS316,
Valve Disc: Aluminum bronze C954,SS304,SS316
Valve Seat: EPDM,NBR
Valve Pressure: PN10, PN16, ANSICL150/CL300/CL600, JIS10K/20K
Working Temperature: -15~85℃
Working media: Seawater, Cooling water,Wastewater, pure water

Swing Check Flange Valve
Body: WCB or SS304,SS316
Disc: SS304, SS316
Seat: Metal hard
Presure: ANSICL150, PN10  PN16, JIS10K 20K
End connection: Flange
Working Temperature: -15~120℃
Working media: Seawater, Cooling water, Wastewater, pure water

Flexible Rubber Joint
Body: WCB, SS304, SS316
Rubber: Natual Rubber, EPDM, NBR Single ball or two balls
End connection: PN10/PN16/ANSICL150/300/JIS10K
Temperature: -15~85℃
